G K Kharate

Digital Electronics

• Broschiertes Buch

Produktbeschreibung

Digital Electronics is specially designed as a textbook for the undergraduate students of Electronics, Communciation, Computer Science, Electrical and Instrumentation Engineering for their introductory course on digital electronics or digital system and design.

---

Hinweis: Dieser Artikel kann nur an eine deutsche Lieferadresse ausgeliefert werden.

Produktdetails

• Verlag: Hurst & Co.
• Seitenzahl: 640
• Erscheinungstermin: 14. Oktober 2012
• Englisch
• Abmessung: 241mm x 160mm x 23mm
• Gewicht: 816g
• ISBN-13: 9780198061830
• ISBN-10: 0198061838
• Artikelnr.: 36445163

Autorenporträt

Dr GK Kharate is currently Principal of Matoshri College of Engineering and Research Centre, Nashik. He is also a fellow member of Institution of Electronics and Telecommunication Engineers (IETE) and a life member of many other professional bodies of repute like Indian Society for Technical Education (ISTE), Institution of Engineers (India) and Computer Society of India. A PhD from University of Pune, Dr Kharate has more than 20 years of teaching experience. He has received a grant of rupees three lakhs from the University of Pune for his research proposal. He has also published a number of articles in national and international journals of repute and organized several conferences and workshops on his areas of study.

Inhaltsangabe

* I. LOGIC FAMILIES
* 1.1 Introduction
* 1.2 Logic Families
* 1.3 Transistor as a Switch
* 1.4 Characteristics of Digital ICs
* 1.4.1. Speed of Operation
* 1.4.2. Power Dissipation
* 1.4.3. Figure of Merit
* 1.4.4. Fan-out
* 1.4.5. Fan-in
* 1.4.6. Current and Voltage Parameters
* 1.4.7. Noise Immunity
* 1.4.8. Power Supply Requirements
* 1.4.9. Operating Temperature
* 1.5. Resistor - Transistor Logic (RTL)
* 1.6. Direct Coupled Transistor Logic (DCTC)
* 1.7. Diode - Transistor Logic (DTL)
* 1.8. Modified Diode - Transistor Logic
* 1.9. Transistor - Transistor Logic (TTL)
* 1.9.1. TTL with passive pull-up
* 1.9.2. TTL with totem - Pole output
* 1.9.3. Wired and Connection
* 1.9.4. TTL with open collector output
* 1.9.5. Unconnected inputs of TTL
* 1.9.6. Tri-StateTTL
* 1.10. TTL Parameters
* 1.11. Commonly used ICs of Standard TTL
* 1.12. Improved TTL series
* 1.12.1. Low Power and High Speed TTL
* 1.12.2. Schottky TTL
* 1.12.3. Lower Power Schottky TTL
* 1.13. Comparison of TTL families
* 1.14. Emitter Coupled Logic
* 1.14.1. ECL Characteristics
* 1.15. Integrated Injection Logic (I2L)
* 1.15.1. I2L Inverter
* 1.15.2. I2L Nandgate
* 1.15.3. I2L Nor gate
* 1.16. MOSFET Logic
* 1.17. NMOS
* 1.17.1. MNOS Inverter
* 1.17.2. NMOS NAND gate
* 1.17.3. NMOS NOR gate
* 1.17.4. Fan-out
* 1.17.5. Propagation delay time
* 1.17.6. Power dissipation
* 1.18. CMOS
* 1.18.1. CMOS inverter
* 1.18.2. CMOS Nand gate
* 1.18.3. CMOS NOR gate
* 1.18.4. Characteristics of CMOS
* 1.18.5. Buffered and Unbuffered gates
* 1.18.6. Transmission gates
* 1.18.7. Open drain outputs
* 1.18.8. High impedance outputs
* 1.18.9. Specifications and Standards
* 1.19. Comparison of CMOS and TTL Families
* 1.20. Interfacing CMOS and TTL Devices
* 1.20.1. TTL Driving CMOS
* 1.20.2. CMOS Driving TTL
* 1.21. Interfacing of ECL and TTL devices
* 1.21.1. TTL driving ECL
* 1.21.2. ECL driving TTL
* 1.22. Key terms and definitions
* 1.23. Summary
* 1.24. Exercise
* 2. NUMBER SYSTEMS AND CODES
* 2.1. Introduction
* 2.2. Number Systems
* 2.3. Interconversion of Numbers
* 2.3.1. Binary to Decimal Conversion
* 2.3.2. Decimal to Binary Conversion
* 2.3.3. Octal to Decimal Conversion
* 2.3.4. Decimal to Octal Conversion
* 2.3.5. Octal to Binary Conversion
* 2.3.6. Binary to Octal Conversion
* 2.3.7. Hexadecimal to Decimal Conversion
* 2.3.8. Decimal to Hexadecimal Conversion
* 2.3.9. Hexadecimal to Binary Conversion
* 2.3.10. Binary to Hexadecimal Conversion
* 2.4. Signed Binary Number
* 2.4.1. Sign-Magnitude Representation
* 2.4.2. 1's Complement Representation
* 2.4.3. 2's Complement Representation
* 2.5. Floating Point Representation of Number
* 2.6. Binary Arithmetic
* 2.6.1. Binary Addition
* 2.6.2. Binary Substraction
* 2.6.3. Binary Multiplication
* 2.6.4. Binary Division
* 2.7. Complement Binary Arithmetic
* 2.7.1. One's (1's) Compliment Arithmetic
* 2.7.2. Two's (2's) Compliment Arithmetic
* 2.8. Arithmetic Overflow
* 2.9. Codes
* 2.9.1. Classification of Codes
* 2.9.2. BINARY Coded Decimal Code (BCD CODE)
* 2.9.2.1. BCD Arithmetic
* 2.9.3. 2-4-2-1 Code
* 2.9.4. Four-Bit BCD Codes
* 2.9.5. Five Bit BCD Codes
* 2.9.6. Biquinary Code
* 2.9.7. Excess-3 Code
* 2.9.8. Gray Code
* 2.9.8.1. Binary to Gray Code Conversion
* 2.9.8.2. Gray to Binary Code Conversion
* 2.9.9. Seven Segment Code
* 2.9.10. Alphanumeric Codes
* 2.9.10.1. ASCII Code
* 2.9.10.2. EBCDIC Code
* 2.9.11. Error Detecting Codes
* 2.9.11.1. Parity Codes
* 2.9.11.2. Block Parity Codes
* 2.9.12. Error Correcting Codes
* 2.9.12.1. Linear Block Code
* 2.9.12.2. Hamming Code
* 2.10. Solved Examples
* 2.11. Summary
* 2.12. Exercises
* 2.13. Problems
* 2.14. Objective Type Questions
* 3:BOOLEAN ALGEBRA AND LOGIC GATES
* 3.1. Introduction
* 3.2. Boolean Algebra
* 3.2.1. Principal of Logic Circuits
* 3.2.2. Boolean Constants, Variables and functions
* 3.2.3. Basic laws of Boolean Algebra
* 3.2.4. Boolean Theorems
* 3.3. Overview of Logic Circuit
* 3.4. Demorgan's Theorems
* 3.5. Standard Representation for logical functions
* 3.5.1. Sum of products from
* 3.5.2. Products of Sums
* 3.6. Minterm and Maxterm
* 3.7. Simplification of Boolean expression
* 3.7.1. Algebraic method
* 3.7.2. Karnaugh Map Simplification
* 3.7.2.1. Representation of k-map
* 3.7.2.2. Representation of truth table on K-map
* 3.7.2.3. Representation of sum of products of K-map
* 3.7.2.4. Representation of product of sum on K-map
* 3.7.2.5 .Grouping the adjacent cells
* 3.8. Simplification of sum of product expression
* 3.9. Simplification of product of sums expression
* 3.10. Don't Care Condition
* 3.11. Five and Six Variable K-map
* 3.12. Quine McCluskey method
* 3.13 Summary
* 3.14.Exercise
* 3.15 Objective Type Questions
* 4: Combinational Logic Circuit
* 4.1. Introduction
* 4.2. Design Procedure for Combinational Logic Circuit
* 4.2.1
* Examples of Combinational Logic Circuit
* 4.3. Adders
* 4.3.1. Half adder
* 4.3.2. Full adder
* 4.3.3. N-Bit Parallel Adder
* 4.3.4. Carry Look Ahead Adder
* 4.3.5 IC 74LS83
* 4.4. Subtractor
* 4.4.1. Half subtractor
* 4.4.2. Full subtractor
* 4.4.3. N-Bit Parallel subtractor
* 4.4.4.Four Bit subtractor Using Adder
* 4.4.4.1
* 1's Complement Subtraction
* 4.4.4.2 1's Complement Subtraction
* 4.5. BCD Adder
* 4.6. BCD Subtractor
* 4.6.1.9's complement
* 4.6.2.9's complement subtraction
* 4.6.3.10'scomplement
* 4.6.4.10's complement subtraction
* 4.7. Arithmetic Logic Unit (ALU)
* 4.8. Comparator
* 4.8.1 IC 7485 [4 Bit-Comparator]
* 4.9. Parity generator
* 4.9.1. Even parity generator
* 4.9.2
* Odd parity generator
* 4.10. Parity checker
* 4.10.1. Even parity checker
* 4.10.2 Odd parity checker
* 4.11 Parity generator/checker (IC74180)
* 4.12 Multiplexer
* 4.12.1. Multiplexer Tree
* 4.12.2. Multiplexer Applications
* 4.13. Demultiplexer
* 4.13.1. Demultiplexer Tree
* 4.13.2. Demultiplexer Applications
* 4.14. Code Converters
* 4.14.1. Binary to BCD Converter
* 4.14.2. BCD to Binary converter
* 4.14.3. BCD to Excess - 3
* 4.14.4. Excess - 3 to BCD Code Converter
* 4.14.5. Binary to Gray Code Converter
* 4.14.6. Gray to Binary Code Converter
* 4.14.7. BCD to Seven-Segment code converter
* 4.14.8. BCD to Seven-Segment display decoder/Driver
* 4.14.9. Basic connection for driving 7-segment displays
* 4.12.10..ICs of Seven-segment Driver/Decoder
* 4.15. PIN diagrams of ICs
* 4.16. Key terms and definitions
* 4.17. Exercise
* 4.18. Objective Type Questions
* 5. SEQUENTIAL LOGIC
* 5.1. Introduction
* 5.2. One bit Memory Cell
* 5.2.1. One bit Memory Cell using Transistors
* 5.2.2. One bit Memory Cell using NAND gates
* 5.2.3. One bit Memory Cell using NOR gates
* 5.3. Clocked S.R. Flip-flop
* 5.3.1. Preset and Clear inputs
* 5.4. J-K Flip-Flop
* 5.4.1. Race-Around condition
* 5.4.2. Master-Slave j-K Flip-Flop
* 5.5. D Flip-Flop
* 5.6. T Flip-Flop
* 5.7. Edge Triggered Flip-Flop
* 5.8. Characterstics of Flip-Flop
* 5.8.1. Propagation Delay (tp)
* 5.8.2. Set-up time (tg)
* 5.8.3. Hold-up time (tn)
* 5.8.4. Maximum check frequency (Fmax)
* 5.8.5. Asynchronous Active Pulse Width
* 5.8.6. Clock high pulse time and low pulse time
* 5.9. Flip-Flop Conversion
* 5.9.1. S-R. Flip-Flop to T Flip-Flop
* 5.9.2. S-R. Flip-Flop to D Flip-Flop
* 5.9.3. S-R. Flip-Flop to J.K. Flip-Flop
* 5.9.4. T Flip-Flop to D Flip-Flop
* 5.9.5. D Flip-Flop to T Flip-Flop
* 5.9.6. J-K. Flip-Flop to T Flip-Flop
* 5.9.7.J-K. Flip-Flop to D Flip-Flop
* 5.10Application of Flip-Flops
* 5.10.1. Bounce Elimination Switch
* 5.10.2. Registers
* 5.10.3Counters
* 5.10.4Random Access Memory
* 5.11. Sequential Logic Design (Introduction)
* 5.12. Registers and Shift registers
* 5.12.1Serial in serial out shift register
* 5.12.2. Serial In parallel out shift register
* 5.12.3Parallel in serial out shift register
* 5.12.4. Parallel In Parallel out shift register
* 5.12.5.Bi-directional shift register
* 5.12.6. Universal register
* 5.13. Applications of Shift register
* 5.13.1. Serial to parallel converter
* 5.13.2. Parallel to serial converter
* 5.13.3. Ring counter
* 5.13.4. Johnson counter and Twisted Ring counter
* 5.13.5. Sequence generator
* 5.13.6. Sequence detector
* 5.14. Commonly used ICs for Shift register
* 5.15.Ripple counter
* 5.15.1. Up/Down Asynchronous counter
* 5.15.2. Modulus 'M' Asynchronous counter
* 5.15.3. Commonly used ICs for Asynchronous counter
* 5.16. Synchronous counter
* 5.17. Flip-Flop Excitation table
* 5.17.1. Excitation table of R-S flip-flop
* 5.17.2. Excitation table of J-K flip-flop
* 5.17.3. Excitation table of T flip-flop
* 5.17.4. Excitation table of DT flip-flop
* 5.18. Synchronous Counter Design
* 5.19. UP/DOWN Counter
* 5.19.1. Commonly used ICs for Synchronous Counter
* 5.19.2
* 74191
* 5.19.3
* 74192
* 5.20. Clocked Sequential Circuit
* 5.20.1
* Moore Circuit
* 5.20.2
* Mealy Circuit
* 5.21 Analysis of Clocked Sequential Circuit
* 5.21.1
* State Table
* 5.21.2
* State Diagram
* 5.22 Design of Clocked Sequential Circuit
* 5.22.1
* State Table
* 5.22.2
* State Diagram
* 5.22.3
* State Reduction
* 5.22.4
* State Assignment
* 5.23 Lockout Condition
* 5.24 Sequence Generator
* 5.25 Sequence Detector
* 5.26. Summary
* 5.27. Exercise
* 5.28. Objective Type Questions
* 6. ASYNCHRONOUS SEQUENTIAL CIRCUITS
* 6.1 Introduction
* 6.2 Design of Fundamental Mode Asynchronous Sequential Circuits
* 6.2.1 Realization using D Flip-Flops
* 6.2.2 Realization using JK Flip-Flops
* 6.3 Design of Pulse Mode Asynchronous Sequential Circuits
* 6.4 Incompletely Specified State Machines
* 6.5 Problems in Asynchronous Circuits
* 6.5.1 Cycles
* 6.5.2 Races
* 6.5.3 Hazards
* 6.6 Design of Hazard Free Switching Circuits
* 6.7 Summary
* 6.8 Exercise
* 6.9 Objective Type Questions
* 7. ALGORITHMIC STATE MACHINES
* 7.1. Introduction
* 7.2. Algorithmic State Machines (ASM)
* 7.2.1. State Box
* 7.2.2. Decision Box
* 7.2.3. Conditional Box
* 7.2.4. ASM block
* 7.3. Realization of ASM charts
* 7.3.1. Traditional Synthesis from an ASM chart
* 7.3.2. Multiplexer Controller method
* 7.4. Solved problems on ASM charts
* 7.5. Register transfer language
* 7.6. RTL Notations
* 7.6.1. Register Transfer statements
* 7.6.1.1Shift operation
* 7.6.1.2. Rotate operation
* 7.6.2. Logical Operation statement
* 7.6.2.1. Inversion operation
* 7.6.2.2. ANDing operation
* 7.6.2.3. ORing operation
* 7.6.3. Connection operation statement
* 7.6.4. Branch statements
* 7.6.4.1. Unconditional branch statement
* 7.6.4.2Conditional branch statement
* 7.6.5. Conditional transfer statement
* 7.6.6. Count statement
* 7.6.7. Declaration statement
* 7.6.8. BUS connection statement
* 7.7. Data Unit Construction from an RTL Description
* 7.8. VHDL
* 7.8.1. Entity - Architecture pair
* 7.8.2. Entity Declaration.
* 7.8.3. Architecture Body
* 7.8.4. Structural Modeling
* 7.8.4.1. Description of Full Adder Architecture
* 7.8.4.2. Declarative part
* 7.8.4.3. Statement part
* 7.8.5. Data Flow Modeling
* 7.8.5.1. WHEN - ELSE Statement
* 7.8.5.2. With - Select Statement
* 7.8.6. Behavioral Style of Modeling
* 7.8.7. Sequential Statements used in behavioral modeling
* 7.8.8. Mixed Style of Modeling
* 7.8.9. Configurations
* 7.8.9.1. Default Configurations
* 7.8.9.2. Component Configuration
* 7.8.10. Important Data Objects in VHDL
* 7.8.10.1. Signal
* 7.8.10.2. Variable
* 7.8.10.3. Constant
* 7.8.11. Important Data Types
* 7.8.12, VHDL Operators
* 7.8.13. VHDL Examples
* 7.9. Summary
* 7.11. Exercise
* 8. PROGRAMMABLE LOGIC DEVICES
* 8.1. Introduction
* 8.2. Programmable Logic Array
* 8.2.1 Internal diagram of PLA
* 8.2.1.1, Input Buffer
* 8.2.1.2. AND matrix
* 8.2.1.3. OR matrix
* 8.2.1.3. Invert/Non-invert matrix
* 8.2.1.4. Output Buffer
* 8.2.2. Combinational Logic Design using PLA
* 8.2.3. Sequential Logic Design using PLA
* 8.3. Programmable Array Logic
* 8.3.1. Internal diagram of PAL
* 8.3.2. Registered Output PALs
* 8.3.3. Configurable PALs
* 8.3.4. Combinational Logic design using PALs
* 8.3.5. Sequential Logic design using PAL
* 8.4. Generic Array Logic Devices (GALs)
* 8.4.1. Architecture of GAL 16V8
* 8.5. Classification of PLDs
* 8.6. Complex Programmable Logic Devices
* 8.6.1. Xilinx XC 9500 CPLD family
* 8.6.1.1. Internal Architecture
* 8.6.1.2. Function - Block Architecture
* 8.6.1.3. I/O Block of XC 9500
* 8.6.1.4. Switch Matrix
* 8.7. Field Programmable Gate Array
* 8.7.1. Xilinx FPGA Architecture
* 8.7.1.1. Configurable Logic Block
* 8.7.1.2. Combinational Function Generator
* 8.7.1.3. Flip-Flop
* 8.7.1.4. Programmable Multiplexers
* 8.7.1.5, Input-Output Block (IOB)
* 8.7.1.6. Switching Matrix Structure
* 8.7.2. XC 4000 Series FPGA
* 8.7.2.1. Configurable Logic Block of XC 400
* 8.7.2.2. Input - Output Mock of XC 4000
* 8.7.2.3. Programmable Interconnects
* 8.8. Application Specific Integrated Circuits (ASICs)
* 8.8.1. Full Custom ASICs
* 8. 8. 2. Semi-Custom ASICs
* 8.8.2.1. Standard Cell Based ASICs
* 8.8.2.2. Gate Array Based ASICs
* 8.9. Solved Examples
* 8.10. Summary
* 8.11. Exercises
* 9. CONVERTERS
* 9.1. Introduction
* 9.2. Basic Principle of D/A Converter
* 9.2.1. Digital to Analog (D/A) converter circuits
* 9.2.2. Digital to Analog Converter
* 9.2.3. Specifications of D/A converter
* Basic principle of Analog to Digital converter
* 9.3.1Analog to Digital converter circuits
* 9.3.2. Parallel Comparator Analog to Digital Converter (Flash
Converter)
* 9.3.3 Successive-approximation A/D converter
* 9.3.4. Dual slope A/D converter
* 9.3.5. Specifications for Analog to Digital Converter
* 9.4. D/A and A/D Converter ICs
* 9.5. ADC 0809 (8 bit A/D converter)
* 9.6. ADC-7109 (12 Bit binary A/D converter)
* 9.7. DAC 0808 (8-bit D/A converter)
* 9.8. Solved Examples
* 9.9. Summary
* 9.10. Exercises
* 10. SEMICONDUCTOR MEMORIES
* 10.1. Introduction
* 10.2. Memory Organization:
* 10.3. Functional Diagram of Memory
* 10.4. Memory Operations
* 10.5. Expanding Memory Size:
* 10.5.1. Expanding Word Size:
* 10.5.2. Expanding word capacity:
* 10.5.3. Expanding Of Word Size and Word Capacity:
* 10.6. Characteristics of Memory Devices:
* 10.7. Classification of Semiconducting Memories:
* 10.8. Read and Write Memory:
* 10.8.1. Static RAM
* 10.8.2. Dynamic RAM:
* 10.8.3. Comparison between SRAM and
* 10.8.4. Commonly Used ICs for RAM:
* 10.9. Read only memory (ROM)
* 10.10. Masked ROM:
* 10.10.1. Programmable Read Only Memory (PROM): 10.10.2. Erasable
Programmable Read Only Memory (EPROM):
* 10.10.3. Electrical Erasable Programmable Read Only Memory (EEPROM):
* 10.10.4. NVRAM
* 10.11. Solved Examples
* 10.12. Summary
* 10.13. Exercises
