Bryan Hart

Digital Signal Transmission

Line Circuit Technology

• Broschiertes Buch

Produktbeschreibung

The coming of digital electronics has given rise to many textbook- outstanding among which are the authoritative works of Douglas Lewin- dealing, in the main, with the combinational and sequential logic aspects of system design. By comparison, the coverage of digital hardware has been meagre: in particular, books on logic circuit interconnections have been scarce in number. When circuits operated at relatively low speeds this did not cause major problems to engineers and students, but the increasing use of fast, and very fast, logic circuits employed extensively in modern digital systems has brought the requirement for properly-designed transmission paths between printed circuit boards, on the boards, and even in the integrated circuit packages themselves. turn, has necessitated a physical understanding of line pulse This, in behaviour, and an ability to design practically appropriate interconnection systems, by a far wider audience of engineers, scientists and students than has been the case hitherto. For many years the study of transmission lines was, primarily, the province of the telecommunications engineer sending high-frequency radio signals to antennas for radiation into space, and the power engineer working at low frequencies (50/60 Hz) but with corresponding wavelengths comparable with the relatively large distances involved in the supply of power from generating stations to remote users. The textbook treatment of lines was well established, but based mainly on the assumption of sinusoidal signals. This 'frequency-domain' approach is not best suited to the understanding of the transmission of digital signals.

---

Hinweis: Dieser Artikel kann nur an eine deutsche Lieferadresse ausgeliefert werden.

Produktdetails

• Verlag: Springer / Springer US / Springer, Berlin
• Artikelnr. des Verlages: 978-0-412-38220-8
• 1988
• Seitenzahl: 160
• Erscheinungstermin: 31. Oktober 1987
• Englisch
• Abmessung: 235mm x 155mm x 9mm
• Gewicht: 254g
• ISBN-13: 9780412382208
• ISBN-10: 0412382202
• Artikelnr.: 29021333

Inhaltsangabe

1 Lumped and distributed circuits.- 2 Characteristics of ideal transmission lines/cables.- 2.1 Equations for an ideal line.- 2.2 Possibility of line pulse reflections.- 2.3 Matching and mismatching.- 2.4 'Phantom generator' interpretation of reflections.- 3 The reflection chart.- 3.1 The Reflection Chart: step-input voltage.- 3.2 Rectangular pulse drive.- 3.3 Input waveforms with finite rise- and fall-times.- 4' sliding-Load-Line' analysis of pulses on lines.- 4.1 Resistive terminations.- 4.2 Nonlinear load: a diode termination.- 4.3 Reflections with logic circuit interconnections.- 5 Time domain reflectometry.- 5.1 Application examples: step and truncated-ramp drive.- 6 Crosstalk.- 6.1 Crosstalk with strip lines.- 6.2 Crosstalk with cable bundles: general comments.- 7 Logic signal transmission: an introduction.- 7.1 Transmission characteristics.- 7.2 Noise rejection in unbalanced and balanced systems.- 7.3 Single-ended, point-to-point transmission: RS232C.- 7.4 Multi-point bidirectional data transmission: RS485.- Appendix A: Résumé of practical line characteristics.- Appendix B: Laboratory demonstration work.- General considerations.- Circuit descriptions and observed waveforms.- Appendix C: General notes on waveform observation.- Lumped systems.- Distributed systems.- Answers (including worked solutions to problems).- References.
