Simon Earland, David Nash, Bill Garden

Guide to European Pressure Equipment

• Broschiertes Buch

Produktbeschreibung

This book provides sensible, practical assistance on pressure equipment. European Pressure Equipment has been written using the day-to-day practical experience of pressure vessel users, manufacturers and suppliers for specifiers, and users of pressure equipment. It has been compiled to provide practical information about all aspects of design, selection and use. The book is aimed at everyone who has technical problems as well as those wanting to know more about pressure equipment and the Pressure Equipment Directive (PED), and also those who want to know who supplies what, and from where in Europe. Aimed at users of pressure vessels in industries such as the power, oil, petrochemical, chemical, pharmaceutical, food, utility and other industries, and also those involved in the specifying and purchasing of pressure vessels and ancillary equipment. The book will of course be of considerable use to designers and manufacturers. Content include: * General * Legislation and standards * Specification of pressure vessels * Design * Manufacture * Inspection and testing * Installation, maintenance and in-service inspection * Units and conversions and materials data * Useful terms translated * Classification guide to manufacturers and suppliers * Reference index

---

Hinweis: Dieser Artikel kann nur an eine deutsche Lieferadresse ausgeliefert werden.

Produktdetails

• Verlag: Wiley
• Seitenzahl: 228
• Erscheinungstermin: 2. Juni 2003
• Englisch
• Abmessung: 298mm x 212mm x 18mm
• Gewicht: 822g
• ISBN-13: 9781860583452
• ISBN-10: 1860583458
• Artikelnr.: 29384157

Autorenporträt

Simon Earland and David Nash are the authors of Guide to European Pressure Equipment, published by Wiley.
