Jean Claude Alacoque

Direct Eigen Control for Induction Machines and Synchronous Motors (eBook, PDF)

• Format: PDF

Produktbeschreibung

Clear presentation of a new control process applied to induction machine (IM), surface mounted permanent magnet synchronous motor (SMPM-SM) and interior permanent magnet synchronous motor (IPM-SM) Direct Eigen Control for Induction Machines and Synchronous Motors provides a clear and consise explanation of a new method in alternating current (AC) motor control. Unlike similar books on the market, it does not present various control algorithms for each type of AC motor but explains one method designed to control all AC motor types: Induction Machine (IM), Surface Mounted Permanent Magnet Synchronous Motor (SMPM-SM) (i.e. Brushless) and Interior Permanent Magnet Synchronous Motor (IPM-SM). This totally new control method can be used not only for AC motor control but also to control input filter current and voltage of an inverter feeding an AC motor. * Accessible and clear, describes a new fast type of motor control applied to induction machine (IM), surface mounted permanent magnet synchronous motor (SM-PMSM) and interior permanent magnet synchronous motor (I-PMSM) with various examples * Summarizes a method that supersedes the two known direct control solutions - Direct Self Control and Direct Torque Control - to be used for AC motor control and to control input filter current and voltage of an inverter feeding an AC motor * Presents comprehensive simulations that are easy for the reader to reproduce on a computer. A control program is hosted on a companion website This book is straight-forward with clear mathematical description. It presents simulations in a way that is easy to understand and to reproduce on a computer, whilst omitting details of practical hardware implementation of control, in order for the main theory to take focus. The book remains concise by leaving out description of sensorless controls for all motor types. The sections on "Control Process", "Real Time Implementation" and "Kalman Filter Observer and Prediction" in the introductory chapters explain how to practically implement, in real time, the discretized control with all three types of AC motors. In order, this book describes induction machine, SMPM-SM, IPM-SM, and, application to LC filter limitations. The appendixes present: PWM vector calculations; transfer matrix calculation; transfer matrix inversion; Eigen state space vector calculation; and, transition and command matrix calculation. Essential reading for Researchers in the field of drive control; graduate and post-graduate students studying electric machines; electric engineers in the field of railways, electric cars, plane surface control, military applications. The approach is also valuable for Engineers in the field of machine tools, robots and rolling mills.

---

Dieser Download kann aus rechtlichen Gründen nur mit Rechnungsadresse in A, B, BG, CY, CZ, D, DK, EW, E, FIN, F, GR, HR, H, IRL, I, LT, L, LR, M, NL, PL, P, R, S, SLO, SK ausgeliefert werden.

Produktdetails

• Verlag: For Dummies
• Seitenzahl: 288
• Erscheinungstermin: 28. September 2012
• Englisch
• ISBN-13: 9781118460627
• Artikelnr.: 37362667

Autorenporträt

Alacoque was previously R&D manager at Alstom Traction in charge of product development in the field of telephone line insulation, traction motor control and wheel-rail adhension control. Prior to this he R&D manager of industrial electronic products for thermal controls and speed drives in CEM, Villeurbanne, then Technical Director of ACEP for power plant engineering. He later joined the R&D team of CORECI as manager for development of process control products. Jean Claude's research interests include discrete-time systems applied to machine control for railways traction during line voltage and wheel-rail adhesion disturbances and with voltage and current saturation. He has authored many technical papers and patents.
