Er-Ping Li

Electrical Modeling and Design for 3D System Integration (eBook, PDF)

3D Integrated Circuits and Packaging, Signal Integrity, Power Integrity and EMC

• Format: PDF

Produktbeschreibung

New advanced modeling methods for simulating the electromagnetic properties of complex three-dimensional electronic systems Based on the author's extensive research, this book sets forth tested and proven electromagnetic modeling and simulation methods for analyzing signal and power integrity as well as electromagnetic interference in large complex electronic interconnects, multilayered package structures, integrated circuits, and printed circuit boards. Readers will discover the state of the technology in electronic package integration and printed circuit board simulation and modeling. In addition to popular full-wave electromagnetic computational methods, the book presents new, more sophisticated modeling methods, offering readers the most advanced tools for analyzing and designing large complex electronic structures. Electrical Modeling and Design for 3D System Integration begins with a comprehensive review of current modeling and simulation methods for signal integrity, power integrity, and electromagnetic compatibility. Next, the book guides readers through: * The macromodeling technique used in the electrical and electromagnetic modeling and simulation of complex interconnects in three-dimensional integrated systems * The semi-analytical scattering matrix method based on the N-body scattering theory for modeling of three-dimensional electronic package and multilayered printed circuit boards with multiple vias * Two- and three-dimensional integral equation methods for the analysis of power distribution networks in three-dimensional package integrations * The physics-based algorithm for extracting the equivalent circuit of a complex power distribution network in three-dimensional integrated systems and printed circuit boards * An equivalent circuit model of through-silicon vias * Metal-oxide-semiconductor capacitance effects of through-silicon vias Engineers, researchers, and students can turn to this book for the latest techniques and methods for the electrical modeling and design of electronic packaging, three-dimensional electronic integration, integrated circuits, and printed circuit boards.

---

Dieser Download kann aus rechtlichen Gründen nur mit Rechnungsadresse in A, B, BG, CY, CZ, D, DK, EW, E, FIN, F, GR, HR, H, IRL, I, LT, L, LR, M, NL, PL, P, R, S, SLO, SK ausgeliefert werden.

Produktdetails

• Verlag: John Wiley & Sons
• Seitenzahl: 384
• Erscheinungstermin: 19. März 2012
• Englisch
• ISBN-13: 9781118166758
• Artikelnr.: 38237447

Autorenporträt

ER-PING LI, PhD, holds an appointment as Chair Professor at Zhejiang University, China, and has also been a principal scientist and director at the Institute of High Performance Computing, Singapore. He is a Fellow of the IEEE and a Fellow of the Electromagnetics Academy. He has received numerous awards and honors in recognition of his professional work from the IEEE and other professional bodies. Dr. Li is a pioneer in the modeling and simulation for signal/power and EMC in integrated circuits and electronic systems packaging. He has chaired or spoken at numerous international conferences and universities, and has also served as editor to several IEEE Transactions.

Inhaltsangabe

Foreword xi
Preface xiii
1. Introduction 1
1.1 Introduction of Electronic Package Integration 1
1.2 Review of Modeling Technologies 6
1.3 Organization of the Book 10
References 11
2. Macromodeling of Complex Interconnects in 3D Integration 16
2.1 Introduction 16
2.1.1 Scope of macromodeling 18
2.1.2 Macromodeling in the picture of electrical modeling of interconnects
19
2.2 Network Parameters: Impedance Admittance and Scattering Matrices 19
2.2.1 Impedance matrix 21
2.2.2 Admittance matrix 22
2.2.3 Scattering matrix 23
2.2.4 Conversion between Z Y and S matrices 24
2.3 Rational Function Approximation with Partial Fractions 25
2.3.1 Introduction 25
2.3.2 Iterative weighted linear least-squares estimator 27
2.4 Vector Fitting (VF) Method 29
2.4.1 Two steps in vector fitting method 29
2.4.2 Fitting vectors with common poles 35
2.4.3 Selection of initial poles 37
2.4.4 Enhancement to the original vector fitting method 38
2.5 Macromodel Synthesis 41
2.5.1 Jordan canonical method for macromodel synthesis 42
2.5.2 Equivalent circuits 46
2.6 Stability Causality and Passivity of Macromodel 48
2.6.1 Stability 48
2.6.2 Causality 50
2.6.3 Passivity assessment 54
2.6.4 Passivity enforcement 58
2.6.5 Other issues 78
2.7 Macromodeling Applied to High-Speed Interconnects and Circuits 79
2.7.1 A lumped circuit with nonlinear components 79
2.7.2 Vertically natural capacitors (VNCAPs) 83
2.7.3 Stripline-to-microstrip line transition with vias 87
2.8 Conclusion 91
References 92
3. 2.5D Simulation Method for 3D Integrated Systems 97
3.1 Introduction 97
3.2 Multiple Scattering Method for Electronic Package Modeling with Open
Boundary Problems 98
3.2.1 Modal expansion of fields in a parallel-plate waveguide (PPWG) 98
3.2.2 Multiple scattering coefficients among cylindrical PEC and perfect
magnetic conductor (PMC) vias 101
3.2.3 Excitation source and network parameter extraction 109
3.2.4 Implementation of effective matrix-vector multiplication (MVM) in
linear equations 117
3.2.5 Numerical examples for single-layer power-ground planes 121
3.3 Novel Boundary Modeling Method for Simulation of Finite-Domain
Power-Ground Planes 127
3.3.1 Perfect magnetic conductor (PMC) boundary 128
3.3.2 Frequency-dependent cylinder layer (FDCL) 128
3.3.3 Validations of FDCL 131
3.4 Numerical Simulations for Finite Structures 133
3.4.1 Extended scattering matrix method (SMM) algorithm for finite
structure simulation 133
3.4.2 Modeling of arbitrarily shaped boundary structures 139
Contents vii
3.5 Modeling of 3D Electronic Package Structure 142
3.5.1 Modal expansions and boundary conditions 143
3.5.2 Mode matching in PPWGs 150
3.5.3 Generalized T-matrix for two-layer problem 158
3.5.4 Formulae summary for two-layer problem 164
3.5.5 Formulae summary for 3D structure problem 169
3.5.6 Numerical simulations for multilayered power-ground planes with
multiple vias 176
3.6 Conclusion 182
References 183
4. Hybrid Integral Equation Modeling Methods for 3D Integration 185
4.1 Introduction 185
4.2 2D Integral Equation Equivalent Circuit (IEEC) Method 186
4.2.1 Overview of the algorithm 186
4.2.2 Modal decoupling inside the power distribution network (PDN) 187
4.2.3 2D integral equation solution of parallel plate mode in power-ground
planes (PGPs) 189
4.2.4 Combinations of transmission and parallel plate modes 194
4.2.5 Cascade connections of equivalent networks 205
4.2.6 Simulation results 214
4.3 3D Hybrid Integral Equation Method 220
4.3.1 Overview of the algorithm 220
4.3.2 Equivalent electromagnetic currents and dyadic green's functions 224
4.3.3 Simulation results 231
4.4 Conclusion 238
References 238
5. Systematic Microwave Network Analysis for 3D Integrated Systems 241
5.1 Intrinsic Via Circuit Model for Multiple Vias in an Irregular Plate
Pair 242
5.1.1 Introduction 242
5.1.2 Segmentation of vias and a plate pair 245
5.1.3 An intrinsic 3-port via circuit model 248
5.1.4 Determination of the virtual via boundary 263
5.1.5 Complete model for multiple vias in an irregular plate pair 267
5.1.6 Validation and measurements 269
5.1.7 Conclusion 280
5.2 Parallel Plane Pair Model 281
5.2.1 Introduction 281
5.2.2 Overview of two conventional Z pp definitions 283
5.2.3 New Z pp definition using the zero-order parallel plate waves 285
5.2.4 Analytical formula for radial scattering matrix S pp in a circular
plate pair 290
5.2.5 BIE method to evaluate S R pp for an irregular plate pair 292
5.2.6 Numerical examples and measurements 296
5.2.7 Conclusion 303
5.3 Cascaded Multiport Network Analysis of Multilayer Structure with
Multiple Vias 305
5.3.1 Introduction 305
5.3.2 Multilayer PCB with vias and decoupling capacitors 307
5.3.3 Systematic microwave network method 308
5.3.4 Validations and discussion 316
5.3.5 Conclusion 324
Appendix: Properties of the Auxiliary Function W mn (x y) 326
References 327
6. Modeling of Through-Silicon Vias (TSV) in 3D Integration 331
6.1 Introduction 331
6.1.1 Overview of process and fabrication of TSV 332
6.1.2 Modeling of TSV 335
6.2 Equivalent Circuit Model for TSV 336
6.2.1 Overview 337
6.2.2 Problem statement: Two-TSV configuration 338
6.2.3 Wideband Pi-type equivalent-circuit model 339
6.2.4 Rigorous closed-form formulae for resistance and inductance 341
6.2.5 Scattering parameters of two-TSV system 345
6.2.6 Results and discussion 346
6.3 MOS Capacitance Effect of TSV 351
6.3.1 MOS capacitance effect 351
6.3.2 Bias voltage-dependent MOS capacitance of TSVs 351
6.3.3 Results and analysis 355
6.4 Conclusion 356
References 358
Index 361
