Don Cornwell, Nicholas Chaplin, Jeremiah Jones

How to Design, Build and Operate a GPS-Guided Autopilot System for RC Aircraft (eBook, PDF)

A Project Report

• Format: PDF

Produktbeschreibung

Project Report from the year 2012 in the subject Engineering - Mechanical Engineering, grade: A, DeVry University, course: ECET 494, language: English, abstract: The objective of this project is to design, build, and operate a GPS-Guided Autopilot system for Radio Controlled Aircraft. This product will have to be small, lightweight, aerodynamic, and modular. It will only have to rely on 1 channel input from the aircraft receiver for the RC/Autopilot switching function. It will have to be able to fly a predetermined route while having the ability for the consumer to override the autopilot feature if desired by using their remote control. Our RC aircraft autopilot system will be interfaced with a computer in order to program the way-points that will make up the flight plan. All of these objectives are critical in order to have a functional RC aircraft autopilot system. Our time frame for completion of this project is 32 weeks and our target for total cost for the build is $500. The product that we are proposing is a GPS-Guided Autopilot System designed for radio-controlled aircraft. This project is a modular RC/Autopilot Aircraft System that will be designed for small, inexpensive, and basic radio controlled unmanned aerial vehicles. Although our target market will be RC hobbyists that are interested in flying their airplanes autonomously, our system will also have the potential to expand to larger markets such as hobbyists flying helicopters as well as Unmanned Aerial Vehicles used in the military. There will be three phases to this project, Phase (1) is our goal and is dedicated as the Autopilot function once the aircraft has reached altitude. Phase (2) is the addition of Autopilot landing, and Phase (3) is the addition of Autopilot takeoff. Phases (2) and (3) are left as optional and will be completed if and only if the team has enough time before the end of the series of Senior Project courses. The project can be broken down into three basic modules to perform these tasks. These modules are the Sensing module, the Receiver/Processor module, and a flight Control module. The combination of these three modules will be assembled to form the autopilot function. The Sensing module will consist of a GPS antenna and a signal processor along with a 2-axis gyroscope and a 3-axis accelerometer. The GPS signal from satellites will be processed into information that will be used by the receiver/processor module to send flight path corrections to the flight control module to keep the aircraft on the programmed path. The flight controls affected by the GPS signals will be the engine speed and the rudder.

---

Dieser Download kann aus rechtlichen Gründen nur mit Rechnungsadresse in A, B, BG, CY, CZ, D, DK, EW, E, FIN, F, GR, HR, H, IRL, I, LT, L, LR, M, NL, PL, P, R, S, SLO, SK ausgeliefert werden.

Produktdetails

• Verlag: GRIN Verlag
• Seitenzahl: 190
• Erscheinungstermin: 12. Mai 2015
• Englisch
• ISBN-13: 9783656960058
• Artikelnr.: 42785736

Autorenporträt

* Self-Starter * Served ACTIVE US ARMY 1987 - 1996 honorably and with distinction * War Veteran 1991 Persian Gulf War * Found DOS/Windows in 1992 and purchased my first Tandy Computer * Attended Austin Peay State University for a short time while serving-Focus was Business * Attended Jefferson Community College, Louisville, KY-Major Computer Information Systems and Computer Programming. * Transferred all credits years later in 2009 to the University of DeVry where I received a B.S. Degree in Electronics Engineering Technology with a minor in Computer Science and Computer Programming * Programming Languages I have studied: BASIC, VBASIC, C, C++, Assembly, JAVA, Relational DBase Programming, Structural and Object-Oriented Programing * Key companies I have worked in the IT industry include: Vencor Health Care-Data Center Computer Operator-Output Specialist, UPS Supply Chains Solutions-Electronic Repair Technician-PC Repair and Printer Repair, Slot Technician in Las Vegas, LeCroy Instruments-Now Teledyne LeCroy - Assembler (Technical) * Non IT Company - Jeffboat ACL Manufacturing Division-Class 1 Welder * Hobbies include PC Gaming - MMORPG MMOAPP, TV-Console Gaming, Web Development, Music, Movies, and Technology. * I am now running my first ever game website at djsgolddiggersgame.com and now I am running this Blog Website. For the first time in my life, I am doing what I, want to do. Back in 1992 when I purchased my first Computer, which was a Tandy Computer, I said then, "One day I am going to make money using my personal computer." I now run a DELL Computer with Intel Architecture and my love for technology just keeps growing bigger-and-better. To me, Technology is "The Glory Of God" as Ezekiel saw it in Ezekiel Chapter 1. I'll never forget that it was my Father God whom blessed me with my earthly and spiritual talents. Thank you God, in the name of Jesus.
