Dehong Xu, Rui Li, Ning He, Jinyi Deng, Yuying Wu

Soft-Switching Technology for Three-phase Power Electronics Converters (eBook, ePUB)

• Format: ePub

Produktbeschreibung

Soft-Switching Technology for Three-phase Power Electronics Converters Discover foundational and advanced topics in soft-switching technology, including ZVS three-phase conversion In Soft-Switching Technology for Three-phase Power Electronics Converters, an expert team of researchers delivers a comprehensive exploration of soft-switching three-phase converters for applications including renewable energy and distribution power systems, AC power sources, UPS, motor drives, battery chargers, and more. The authors begin with an introduction to the fundamentals of the technology, providing the basic knowledge necessary for readers to understand the following articles. The book goes on to discuss three-phase rectifiers and three-phase grid inverters. It offers prototypes and experiments of each type of technology. Finally, the authors describe the impact of silicon carbide devices on soft-switching three-phase converters, studying the improvement in efficiency and power density created via the introduction of silicon carbide devices. Throughout, the authors put a special focus on a family of zero-voltage switching (ZVS) three-phase converters and related pulse width modulation (PWM) schemes. The book also includes: * A thorough introduction to soft-switching techniques, including the classification of soft-switching for three phase converter topologies, soft-switching types and a generic soft-switching pulse-width-modulation known as Edge-Aligned PWM * A comprehensive exploration of classical soft-switching three-phase converters, including the switching of power semiconductor devices and DC and AC side resonance * Practical discussions of ZVS space vector modulation for three-phase converters, including the three-phase converter commutation process * In-depth examinations of three-phase rectifiers with compound active clamping circuits Perfect for researchers, scientists, professional engineers, and undergraduate and graduate students studying or working in power electronics, Soft-Switching Technology for Three-phase Power Electronics Converters is also a must-read resource for research and development engineers involved with the design and development of power electronics.

---

Dieser Download kann aus rechtlichen Gründen nur mit Rechnungsadresse in A, B, BG, CY, CZ, D, DK, EW, E, FIN, F, GR, HR, H, IRL, I, LT, L, LR, M, NL, PL, P, R, S, SLO, SK ausgeliefert werden.

Produktdetails

• Verlag: John Wiley & Sons
• Seitenzahl: 496
• Erscheinungstermin: 9. Dezember 2021
• Englisch
• ISBN-13: 9781119602552
• Artikelnr.: 63207498

Autorenporträt

Dehong Xu, PhD, is Full Professor in College of Electrical Engineering at Zhejiang University. Rui Li, PhD, is Full Professor in the Department of Electrical Engineering, School of Electronics, Information and Electrical Engineering at Shanghai Jiao Tong University. Ning He, PhD, is Firmware Design Principal Engineer in Delta Electronics (Shanghai) Co., Ltd. Jinyi Deng is a PhD student in Power Electronics in the College of Electrical Engineering at Zhejiang University. Yuying Wu is a PhD student in Power Electronics in the College of Electrical Engineering at Zhejiang University.

Inhaltsangabe

PREFACE

NOMENCLATURE

PART 1: FUNDAMENTAL OF SOFT SWITCHING

Chapter 1 Introduction

1.1 Requirement for three-phase power conversions

1.1.1 Three-phase converters

1.1.2 Switching frequency vs. conversion efficiency and power density

1.1.3 Switching frequency and impact of soft-switching technology

1.2 Concept of soft-switching technique

1.2.1 Soft-switching types

1.2.2 Soft-switching technique for three phase converters

1.3 Applications of soft-switching to three-phase converters

1.3.1 Renewable energy and power generation

1.3.2 Energy storage systems

1.3.3 Distributed FACTS devices

1.3.4 Uninterruptible power supply

1.3.5 Motor drives

1.3.6 Fast EV Chargers

1.4 The topics of this book

References

Chapter 2 Basics of soft-switching three-phase converters

2.1 Introduction

2.2 Switching characteristics of three-phase converters

2.2.1 Control of three-phase converters

2.2.2 Switching transient process and switching loss

2.2.3 Diode turn-off and reverse recovery

2.2.4 Stray inductance on switching process

2.2.5 Snubber

2.3 Classification of soft-switching three-phase converters

2.4 DC-side resonance converters

2.4.1 Resonant DC link converters

2.4.2 Active-clamped resonant DC-link (ACRDCL) converter

2.4.3 ZVS-SVM active clamping three-phase converter

2.4.3.1. Active clamping DC-DC converter

2.4.3.2. Active-clamping three-phase converter

2.5 AC-side resonance converters

2.5.1 Auxiliary resonant commutated pole converter

2.5.2 Coupled-inductor zero-voltage-transition (ZVT) inverter

2.5.3 Zero-current-transition (ZCT) inverter

2.6 Soft-switching inverter with TCM control

2.7 Summary

References

Chapter 3 Soft-switching PWM control for Active Clamped Three-phase Converters

3.1 Introduction

3.2 PWM of three-phase converters

3.3 Edge-Aligned PWM

3.4 ZVS converter circuit with EA-PWM

3.4.1 Stage analysis

3.4.2 ZVS conditions

3.4.1.1 The 1st resonant stage

3.4.1.2 The 2nd resonant stage

3.4.1.3 Steady conditions

3.4.3 Impact of PWM scheme and load on ZVS condition

3.5 Control diagram of the converter with EA-PWM

3.6 ZVS-SVM

3.6.1 Vector sequence

3.6.2 ZVS-SVM scheme

3.6.3 Characteristics of the converter with ZVS-SVM

3.7 Summary

References

PART 2: ZVS-SVM APPLIED TO THREE-PHASE RECTIFIERS

Chapter 4 Three-phase Rectifier with Compound Active Clamping Circuit

4.1 Introduction

4.2 Operation principle of CAC rectifier

4.2.1 Space vector of three-phase grid voltage

4.2.2 Space vector modulation of three-phase converter

4.2.3 Switching scheme of CAC rectifier

4.3 Circuit analysis

4.3.1 Operation stage analysis

4.3.2 Resonant stages analysis

4.3.3 Steady state analysis

4.3.4 Soft switching condition

4.3.5 Control technique of compound active clamping three-phase rectifier

4.4 Prototype design

4.4.1 Specifications of a 40 kW rectifier

4.4.2 Parameter design

4.4.3 Experiment platform and testing results

4.5 Summary

References

Chapter 5 Three-phase Rectifier with Minimum Voltage Active Clamping Circuit

5.1 Introduction
